B127, also known as the VCL was was designed to be flexible and reconfigurable so that changes and/or upgrades to the system are easy to implement as technology improves. The current rear projection system includes 6 projectors in a 3 (wide) x 2 (high) array that creates a blended display 30′-6″ wide and 15′-3″ tall with 3072 x 1536 pixels in total.
The screen consists of 3 flat vertical panels at a 20-degree angle to each other. This creates a screen that “curves” around the user, thereby creating a semi-immersive experience. However, given the large room, we can also project to an audience of 20 – 60 people. This display systems support research and education in virtual and augmented reality applications in planning, design, construction, and operations.
Dimensions and Pricing:
| Room # | Square Feet | Capacity Theater Set |
Capacity Classroom Set |
Tier 1 CBE Use |
Tier 2 Non-CBE Use |
Tier 3 Non-UW Use |
| B127 | 1,187 | 65 | 45 | $ 100.00 | $ 150.00 | $ 200.00 |
Layout Examples:
